Akino · 2D6C/6H.804K

ERATO 6 — 4-CMOS 4K LED+NIR with recording

Erato 6 camera console and head (Art. 2D6C/6H.804K): four-CMOS 4K platform with dedicated NIR channel, IR Boost, onboard recording, and camera-head controls for RGB, overlay, and IR modes during fluorescence-guided surgery.

Four-CMOS sensor with dedicated near-infrared channel and IR Boost
One-click RGB / RGB+IR switching with PIP and adjustable NIR intensity
4 × 12G-SDI and HDMI 2.0 outputs for 4K tower and archive routing

RGB + NIR4K outputICG modes

ERATO 6 — 4-CMOS 4K LED+NIR with recording — primary diagram

Oshano / tower compatibility

Configure Erato 6 with matched NIR optics, LED/IR illumination, and display tier for fluorescence-guided procedures.

Component	Oshano system	Standard tower
Light source	Staro 3 LED/IR	Staro 2 or Staro 3
NIR laparoscope	5 mm / 10 mm UHD	5 mm / 10 mm UHD
Surgical display	32″ / 55″ 4K (TriView)	32″–55″ 4K
Recorder	AREK.NA4K (optional)	Onboard + AREK.NA4K
Endoscopy cart	Aero ENCT.2000	Navo or Aero

Key specifications

Sensor platform: 4-CMOS integrated
Resolution: 3840 × 2160 (4K UHD)
Fluorescence: ICG — RGB, overlay, IR
Recording: Onboard 4K-capable

Full specification

Article: 2D6C/6H.804K
RGB sensors: 3 × CMOS (4K)
NIR sensor: 1 × CMOS (parallel capture)
Camera-head controls: 4 buttons · 8 functions (default)
Mode switching: RGB · RGB+IR · IR · PIP
NIR intensity: Independent adjustment (with Staro 3)
4K outputs: 4 × 12G-SDI · 1 × HDMI 2.0
HD outputs: 1 × DVI-D · 2 × HD-SDI
Camera-head mass: 220 g (without cable)
Light-source coupling: Automatic exposure; no intensity link required
